GFMJ-600 VRLA Deep Cycle Gel Battery 600AH High Security

Minimum Order Quantity : 1PCS Price : $243/pcs
Brand Name: SHOTO Model Number: GFMJ-600

Detail Information

Model Number: GFMJ-600 Nominal Capacity: 600AH
Weight: 46.5KG Voltage: 2V
Size: 145*206*645/677mm Application: Telecom / Energy Storage / Electrical System
Color: Grey Product Name: 2V 600AH Gel Battery
Type: Gel Lead Acid Battery Terminal: M10
High Light:

GFMJ-600 VRLA Deep Cycle Gel Battery

,

600AH Deep Cycle Gel Battery

,

600AH vrla gel battery

Product Description

Product Description



Shoto GFMJ - 600 VRLA Maintenance - free Sealed Lead - acid Gel Battery for Telecom / Energy Storage / UPS





Main Applications

1. Deep cycling energy storage application
2. Solar& wind energy storage system
3. O-grid & bad-grid hybrid sites
4. Floating applications for telecom sites

Benefits

1. Long life design for cyclic or oat application
2. Excellent charge acceptability and deep cycling performance
3. Excellent over discharge recovery capability
4. Superior charging & discharging ability in low current
5. Extend service life under high temperature

Technical Features

1. According to DIN-40742 and IEC-61427 standards, 20 years design life

2. Tubular plate & special gel electrolyte, which can prevent active material falling and avoid acid stratification
3. High stability and security, millions of batteries are in service
4. Higher thermal capacity & better thermal diffusivity2. Positive grid is made of special multi alloy, which overcomes the shortcomings of early capacity loss. It has long service life under both float charge and cycle utilization.



GFMJ-600 VRLA Deep Cycle Gel Battery 600AH High Security 0
Normal Voltage
2V
Capacity
600Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight
46.5 kg (102.51 lbs)

Dimensions
Length: 145 mm (5.71 in)
Width: 206 mm (8.11 in)
Height: 645 mm (25.39 in)
Total height: 677 mm (26.65 in)
Internal Resistance (full charged)
0.35 mΩ @ 25˚C(77˚F)
Short- circuit current
5706A
Self Discharge @25˚C(77˚F)
Less than 4% after 28 days storage

Operating Temperature Range
Discharge: -20˚C ~ 50˚C(-4˚F ~ 122˚F)
Charge: -20˚C ~ 50˚C(-4˚F ~ 122˚F)
Storage: -5˚C ~ 40˚C(41˚F ~ 104˚F)
Recommended Operating Temperature
20˚C ~ 25˚C (68˚F ~ 77˚F)
Recommended Charging Current
90A
Charging Voltage @25˚C(77˚F)
Float: 2.23 V/cell
Equalize: 2.35 V/cell
Terminal
M10

Capacity Affected by Temperature
105 % @ 40˚C
74 % @ 0˚C
50 % @ -20˚
Design life @25°C
20 years
