420AH 10hr Tubular Valve Regulated Gel Battery 2V GFMJ-420 for Electrical System

Minimum Order Quantity : 1PCS Price : $178/pcs
Brand Name: SHOTO Model Number: GFMJ-420

Detail Information

Model Number: GFMJ-420 Nominal Capacity: 420AH
Weight: 32.5KG Voltage: 2V
Size: 145*206*470/502mm Application: Telecom / Energy Storage / Electrical System
Color: Grey Battery Type: Gel Battery
Product Name: 2V 420AH Gel Battery Terminal: M10
High Light:

420AH Valve Regulated Gel Battery

,

10hr valve regulated gel battery

,

420AH tubular gel battery

Product Description

Product Description



Shoto GFMJ - 420 VRLA Maintenance - free Sealed Lead - acid Gel Battery for Telecom / Energy Storage / UPS





Main Applications

1. Deep cycling energy storage application
2. Solar& wind energy storage system
3. O-grid & bad-grid hybrid sites
4. Floating applications for telecom sites

Benefits

1. Long life design for cyclic or oat application
2. Excellent charge acceptability and deep cycling performance
3. Excellent over discharge recovery capability
4. Superior charging & discharging ability in low current
5. Extend service life under high temperature

Technical Features

1. According to DIN-40742 and IEC-61427 standards, 20 years design life

2. Tubular plate & special gel electrolyte, which can prevent active material falling and avoid acid stratification
3. High stability and security, millions of batteries are in service
4. Higher thermal capacity & better thermal diffusivity2. Positive grid is made of special multi alloy, which overcomes the shortcomings of early capacity loss. It has long service life under both float charge and cycle utilization.



Normal Voltage
2V
Capacity
420Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight
32.5 kg (71.65 lbs)

Dimensions
Length: 145 mm (5.71 in)
Width: 206 mm (8.11 in)
Height: 470 mm (18.5 in)
Total height: 502 mm (19.76 in)
Internal Resistance (full charged)
0.42 mΩ @ 25˚C(77˚F)
Short- circuit current
4750A
Self Discharge @25˚C(77˚F)
Less than 4% after 28 days storage

Operating Temperature Range
Discharge: -20˚C ~ 50˚C(-4˚F ~ 122˚F)
Charge: -20˚C ~ 50˚C(-4˚F ~ 122˚F)
Storage: -5˚C ~ 40˚C(41˚F ~ 104˚F)
Recommended Operating Temperature
20˚C ~ 25˚C (68˚F ~ 77˚F)
Recommended Charging Current
63A
Charging Voltage @25˚C(77˚F)
Float: 2.23 V/cell
Equalize: 2.35 V/cell
Terminal
M10

Capacity Affected by Temperature
105 % @ 40˚C
74 % @ 0˚C
50 % @ -20˚
Design life @25°C
20 years



Technical Parameters


Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

420AH 10hr Tubular Valve Regulated Gel Battery 2V GFMJ-420 for Electrical System 0

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

420AH 10hr Tubular Valve Regulated Gel Battery 2V GFMJ-420 for Electrical System 1

Performance Curve

420AH 10hr Tubular Valve Regulated Gel Battery 2V GFMJ-420 for Electrical System 2
