M10 Terminal Tubular Lead Acid Battery 2V 350AH Solar Gel Batteries

Contact Now

M10 Terminal Tubular Lead Acid Battery 2V 350AH Solar Gel Batteries

Name: M10 Terminal Tubular Lead Acid Battery 2V 350AH Solar Gel Batteries
Brand: SHOTO
SKU: GFMJ-350
Price: 145 USD
Availability: InStock
Rating: 5 (152 reviews)

Minimum Order Quantity :	1PCS	Price :	$145/pcs

Brand Name:	SHOTO	Model Number:	GFMJ-350

Detail Information
Model Number:	GFMJ-350	Nominal Capacity:	350AH
Weight:	27.5KG	Size:	124206470/502mm
Application:	Telecom / Energy Storage / Electrical System	Color:	Grey
Battery Type:	Gel Battery	Capacity:	350Ah 10hr Rate
Product Name:	2V 350AH Gel Battery	Voltage:	2V
Terminal:	M10
High Light:	M10 Terminal Tubular Lead Acid Battery , 350AH Tubular Lead Acid Battery , 350AH Solar Gel Batteries

Product Description

Shoto GFMJ - 350 VRLA Maintenance - free Sealed Lead - acid Gel Battery for Telecom / Energy Storage / UPS

Normal Voltage		2V
Capacity		350Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		27.5 kg (60.63 lbs)
Dimensions		Length: 124 mm (4.88 in) Width: 206 mm (8.11 in) Height: 470 mm (18.5 in) Total height: 502 mm (19.76 in)
Internal Resistance (full charged)		0.46 mΩ @ 25˚C(77˚F)
Short- circuit current		4305A
Self Discharge @25˚C(77˚F)		Less than 4% after 28 days storage
Operating Temperature Range		Discharge: -20˚C ～ 50˚C(-4˚F ～ 122˚F) Charge: -20˚C ～ 50˚C(-4˚F ～ 122˚F) Storage: -5˚C ～ 40˚C(41˚F ～ 104˚F)
Recommended Operating Temperature		20˚C ～ 25˚C (68˚F ～ 77˚F)
Recommended Charging Current		52.5A
Charging Voltage @25˚C(77˚F)		Float: 2.23 V/cell Equalize: 2.35 V/cell
Terminal		M10
Capacity Affected by Temperature		105 % @ 40˚C 74 % @ 0˚C 50 % @ -20˚
Design life @25°C		20 years

Main Applications

1. Deep cycling energy storage application
2. Solar& wind energy storage system
3. O-grid & bad-grid hybrid sites
4. Floating applications for telecom sites

Benefits

1. Long life design for cyclic or oat application
2. Excellent charge acceptability and deep cycling performance
3. Excellent over discharge recovery capability
4. Superior charging & discharging ability in low current
5. Extend service life under high temperature

Technical Features

1. According to DIN-40742 and IEC-61427 standards, 20 years design life

2. Tubular plate & special gel electrolyte, which can prevent active material falling and avoid acid stratification
3. High stability and security, millions of batteries are in service
4. Higher thermal capacity & better thermal diffusivity2. Positive grid is made of special multi alloy, which overcomes the shortcomings of early capacity loss. It has long service life under both float charge and cycle utilization.
