UL VRLA Sealed Lead Acid Battery Gel 2 Volt 200ah Battery For Energy Storage

Contact Now

UL VRLA Sealed Lead Acid Battery Gel 2 Volt 200ah Battery For Energy Storage

Minimum Order Quantity :	10pcs

Place of Origin:	CHINA	Brand Name:	SHOTO
Certification:	CE / UL / ISO9001 / ISO14001	Model Number:	GFMJ - 200 VRLA

Detail Information

Highlight:

UL VRLA Sealed Lead Acid Battery

200ah VRLA Sealed Lead Acid Battery

UL VRLA Gel 2 Volt 200ah Battery

Product Description

Deep Cycle Gel Battery-200 VRLA Maintenance-free Sealed Lead-acid Gel Battery

Overview

Quick Details

Brand Name:: Shoto

Model Number:: GFMJ-200

Nominal Capacity:: 200AH

Place of Origin:: Jiangsu, China

Weight:: 18.2KG

Maintenance Type:: Free

Voltage:: 2V

Size:: 103*206*354/386mm

Sealed Type:: Sealed

Usage:: Telecom, Energy Storage and Electrical System

Application:: Telecom / Energy Storage / Electrical System

Color:: Grey

Certificate:: CE / UL / ISO9001 / ISO14001

Battery type:: Gel Battery

Type:: Gel Lead Acid Battery

Product name:: 2V 200AH Gel Battery

Capacity:: 200Ah 10hr Rate

Material:: High Pure Lead

Terminal:: M10

Supply Ability

Supply Ability: 10000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: To be packed in strong wooden cases or cartons, suitable for long distance ocean, parcel post or air freight transportation as well as changing climate and with good resistance to moisture and shocks.

Port: Shanghai Port

Lead Time:: Shipped in 45 days after payment

Product Description

Shoto GFMJ - 200 VRLA Maintenance - free Sealed Lead - acid Gel Battery for Telecom / Energy Storage / UPS

Normal Voltage		2V
Capacity		200Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		18.2 kg (40.12 lbs)
Dimensions		Length: 103 mm (4.06 in) Width: 206 mm (8.11 in) Height: 354 mm (13.94 in) Total height: 386 mm (15.20 in)
Internal Resistance (full charged)		0.68 mΩ @ 25˚C(77˚F)
Short- circuit current		2956A
Self Discharge @25˚C(77˚F)		Less than 4% after 28 days storage
Operating Temperature Range		Discharge: -20˚C ～ 50˚C(-4˚F ～ 122˚F) Charge: -20˚C ～ 50˚C(-4˚F ～ 122˚F) Storage: -5˚C ～ 40˚C(41˚F ～ 104˚F)
Recommended Operating Temperature		20˚C ～ 25˚C (68˚F ～ 77˚F)
Recommended Charging Current		30A
Charging Voltage @25˚C(77˚F)		Float: 2.23 V/cell Equalize: 2.35 V/cell
Terminal		M10
Capacity Affected by Temperature		105 % @ 40˚C 74 % @ 0˚C 50 % @ -20˚
Design life @25°C		20 years

Main Applications

1. Deep cycling energy storage application
2. Solar& wind energy storage system
3. O-grid & bad-grid hybrid sites
4. Floating applications for telecom sites

Benefits

1. Long life design for cyclic or oat application
2. Excellent charge acceptability and deep cycling performance
3. Excellent over discharge recovery capability
4. Superior charging & discharging ability in low current
5. Extend service life under high temperature

Technical Features

1. According to DIN-40742 and IEC-61427 standards, 20 years design life

2. Tubular plate & special gel electrolyte, which can prevent active material falling and avoid acid stratification
3. High stability and security, millions of batteries are in service
4. Higher thermal capacity & better thermal diffusivity2. Positive grid is made of special multi alloy, which overcomes the shortcomings of early capacity loss. It has long service life under both float charge and cycle utilization.

Technical Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
