200Ah 12V Front Terminal Battery Maintenance Free Lead Acid AGM Battery M6 Terminal

Name: 200Ah 12V Front Terminal Battery Maintenance Free Lead Acid AGM Battery M6 Terminal
Brand: SHOTO
SKU: 6-FMX-200
Price: 252 USD
Availability: InStock
Rating: 4.5 (155 reviews)

Minimum Order Quantity :	1PCS	Price :	$252/pcs

Brand Name:	SHOTO	Model Number:	6-FMX-200

Detail Information
Model Number:	6-FMX-200	Nominal Capacity:	200Ah
Weight:	57kg	Size:	559125315/315mm
Voltage:	12V	Application:	Telecom / Energy Storage / UPS
Product Name:	12V 200AH Lead Acid Battery	Terminal:	M6
High Light:	AGM 12V Front Terminal Battery , M6 Terminal Front Terminal Battery , M6 Front Terminal lead acid agm battery

Product Description

Shoto 6 - FMX - 200 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS

Normal Voltage		12V
Capacity		200Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		57 kg (125.66 lbs)
Dimensions		Length: 559 mm Width: 125 mm Height: 315 mm Total Height: 315 mm
Internal Resistance (full charged)		3.2 mΩ
Short-circuit Current		2852 A
Self Discharge @25˚C(77˚F)		Less than 4% after 30 days storage
Operating Temperature Range		Discharge: -40˚C ～ 50˚C(-40˚F ～ 122˚F) Charge: -20˚C ～ 45˚C(-4˚F ～ 113˚F) Storage: -20˚C ～ 40˚C(-4˚F ～ 104˚F)
Recommended Operating Temperature		15˚C ～ 25˚C (59˚F ～ 77˚F)
Recommended Charging Current		40 A
Charging Voltage @25˚C(77˚F)		Float: 2.23 V/cell Cycle: 2.35 V/cell
Terminal		M6
Capacity Affected by Temperature		103 % @ 40˚C 85 % @ 0˚C 60 % @ -20˚
Design life @25°C		12 years

Main Applications

1. Telecom site
2. Outdoor base station
3. Floating operation site
4. UPS

Benefits

1. Front terminal design, easy access for faster installation and maintainence
2. Optimal energy density, save oor space
3. No leakage and no acid smog spray during the operation

Technical Features

1. Excellent capacity retention rate

2. Long life oat service design

3. Excellent over discharge recovery

4. capability

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
