26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free

Minimum Order Quantity : 50 Delivery Time : 25workdays
Payment Terms : Western Union, L/C, T/T
Place of Origin: CHINA Brand Name: shoto
Certification: CE/TUV

Detail Information

Name: 26Ah 12v Sealed Lead Acid Battery Size: 165*125*170/174mm
Capacity: 24Ah 10hr Rate Material: High Pure Lead
Sealed Type: Sealed Advantage: Maintenance - Free
High Light:

26Ah 12v Sealed Lead Acid Battery

,

12v Sealed Lead Acid Battery Rechargeable

,

26Ah 12v rechargeable lead acid battery

Product Description

26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free
Product Description

Shoto 6 - GFM - 26 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS

♦ Strong heat dissipation and wide operating temperature range
♦ Avoid acid mist being separated out , environment friendliness
♦ Efficient venting system release excessive gas automatically

26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 0
Normal Voltage
12V
Capacity
26Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight
9.0 kg (19.8 lbs)

Dimensions
Length: 165 mm
Width: 125 mm
Height: 170 mm
Total height: 174 mm
Internal Resistance (full charged)
11.3 mΩ
Maximum Discharge Current
148A (5sec)
Self Discharge @25˚C(77˚F)
Less than 8% after 90 days storage

Operating Temperature Range
Discharge: -40˚C ~ 50˚C(-40˚F ~ 122˚F)
Charge: -20˚C ~ 45˚C(-4˚F ~ 113˚F)
Storage: -20˚C ~ 40˚C(-4˚F ~ 104˚F)
Recommended Operating Temperature
15˚C ~ 25˚C (59˚F ~ 77˚F)
Maximum Charging Current Limited
4.8A
Charging Voltage @25˚C(77˚F)
Float: 2.25 V/cell
Cycle: 2.35 V/cell
Terminal
M6

Capacity Affected by Temperature
105 % @ 40˚C
85 % @ 0˚C
60 % @ -20˚
Design life @25°C
10 years

Main Applications

1. Backup power for telecom and signal system
2. Military field, railway system, power system
3. UPS & emergency lighting system
4. Fire alarm and security system

Benefits

1. 10 years design life
2. Safely and reliably sealed
3. High energy density, low internal resistance and low discharge rate
4. Excellent charging acceptability and high sealed reaction effciency

Technical Features

1. Adopt high strength ABS plastic, compact structure for battery container and valve, good impact resistance,and shock resistant performance.

2. Adopt multi-element alloy grids, low internal resistance, good corrosion resistance ability and charging acceptability.
3. New production process for plate, improve the utilization of active materiality.

4. High-purity electrolyte and special additives (ZL02112896.0), low self-discharge.

5. Multi-Iayer seal technology and special seal glue, no leakage and no acid mist escape, safe and reliable.

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 1

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 2

Performance Curve

26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 3
Our Products
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 4
Our Company
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 5
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 6
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 7
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 8
Our Customers
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 9
Packing & Delivery
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 10
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 11
26Ah 12v Sealed Lead Acid Battery Rechargeable Maintenance - Free 12
Our most professional packaging
process

Transport of large trucks to the seaport

And international transport cooperation

Our Service

We will reply you for your inquiry in 24 hours.

After sending, we will track the products for you timely, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.

FAQ

Q1. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, CIP, DDP.

Q3. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q4. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q5: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
