12 Volt 100 Amp Hour Agm Lead Acid Battery For Telecom UPS

Name: 12 Volt 100 Amp Hour Agm Lead Acid Battery For Telecom UPS
Brand: shoto
SKU: 6-GFM-100Ah
Price: 1 USD
Availability: InStock
Rating: 4.9 (146 reviews)

Payment Terms :	L/C, T/T, Western Union

Place of Origin:	CHINA	Brand Name:	shoto
Certification:	CE / UL / ISO9001 / ISO18001 / ISO14001	Model Number:	6-GFM-100Ah

Detail Information
Product Name:	Agm Lead Acid Battery	Voltage:	12V
Size:	331174218/225mm	Capacity:	100Ah 10hr Rate
Nominal Capac:	100AH	Battery Type:	Sealed VRLA Lead Acid Battery
Terminal:	M6
High Light:	100 Amp Hour Agm Lead Acid Battery , 12 Volt Agm Lead Acid Battery , 12 volt 100 amp hour sealed lead acid battery UPS

Product Description

Agm Lead Acid Battery is used in Rechargeable Lanterns /Power tools/lawn mowers/vacuum cleaners/ Portable Audio & Video equipment /Portable computing equipment/
Electric driven wheelchairs or bicycle /

Toys and consumer eletronics/Solar power devices Uninterruptible power supply/ Emergency lighting system /Security system and fire alarm /Communication equipment /Medical equipment

Shoto 6 - GFM - 100 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS

Normal Voltage		12V
Capacity		100Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		29.5 kg (65.1 lbs)
Dimensions		Length: 331 mm Width: 174 mm Height: 211 mm Total height: 220 mm
Internal Resistance (full charged)		4.2 mΩ
Maximum Discharge Current		620A (5sec)
Self Discharge @25˚C(77˚F)		Less than 8% after 90 days storage
Operating Temperature Range		Discharge: -40˚C ～ 50˚C(-40˚F ～ 122˚F) Charge: -20˚C ～ 45˚C(-4˚F ～ 113˚F) Storage: -20˚C ～ 40˚C(-4˚F ～ 104˚F)
Recommended Operating Temperature		15˚C ～ 25˚C (59˚F ～ 77˚F)
Maximum Charging Current Limited		20A
Charging Voltage @25˚C(77˚F)		Float: 2.25 V/cell Cycle: 2.35 V/cell
Terminal		M6
Capacity Affected by Temperature		105 % @ 40˚C 85 % @ 0˚C 60 % @ -20˚
Design life @25°C		10 years

Main Applications

1. Backup power for telecom and signal system
2. Military field, railway system, power system
3. UPS & emergency lighting system
4. Fire alarm and security system

Benefits

1. 10 years design life
2. Safely and reliably sealed
3. High energy density, low internal resistance and low discharge rate
4. Excellent charging acceptability and high sealed reaction effciency

Technical Features

1. Adopt high strength ABS plastic, compact structure for battery container and valve, good impact resistance,and shock resistant performance.

2. Adopt multi-element alloy grids, low internal resistance, good corrosion resistance ability and charging acceptability.
3. New production process for plate, improve the utilization of active materiality.

4. High-purity electrolyte and special additives (ZL02112896.0), low self-discharge.

5. Multi-Iayer seal technology and special seal glue, no leakage and no acid mist escape, safe and reliable.

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
