VRLA Maintenance Free Lead Acid AGM Spiral Cell Battery 12v 75ah AGM Battery

Contact Now

VRLA Maintenance Free Lead Acid AGM Spiral Cell Battery 12v 75ah AGM Battery

Name: VRLA Maintenance Free Lead Acid AGM Spiral Cell Battery 12v 75ah AGM Battery
Brand: shoto
SKU: 6-SPB-50A
Price: 1 USD
Availability: InStock
Rating: 4.8 (142 reviews)

Place of Origin:	Jiangsu, China	Brand Name:	shoto
Certification:	CE / UL / ISO9001 / ISO18001 / ISO14001	Model Number:	6-SPB-50A

Detail Information
Model Number:	6-SPB-75A	Nominal Capacity:	75AH
Weight:	25KG	Maintenance Type:	Free
Voltage:	12V	Size:	263178.5240/249mm
Sealed Type:	Sealed	Usage:	Telecom, Energy Storage And UPS
Application:	Telecom / Energy Storage / UPS	Battery Type:	Sealed VRLA Lead Acid Battery
High Light:	ISO14001 VRLA AGM Spiral Cell Battery , VRLA 12v 75ah AGM Spiral Cell Battery , 6-SPB-75A 12v 75ah agm battery

Product Description

Shoto 6 - SPB - 75 VRLA Maintenance - free Lead - acid AGM Spiral Battery for Telecom / Energy Storage / UPS

Overview

Quick Details

Brand Name:: Shoto

Model Number:: 6-SPB-75

Nominal Capacity:: 75AH

Place of Origin:: Jiangsu, China

Weight:: 25KG

Maintenance Type:: Free

Voltage:: 12V

Size:: 263*178.5*240/249mm

Sealed Type:: Sealed

Usage:: Telecom, Energy Storage and UPS

Application:: Telecom / Energy Storage / UPS

Color:: Grey

Certificate:: CE / UL / ISO9001 / ISO18001 / ISO14001

Battery type:: Sealed VRLA Lead Acid Battery

Type:: Lead Acid Battery

Product name:: 12V 75AH Lead Acid Battery

Capacity:: 75Ah 10hr Rate

Material:: High Pure Lead

Terminal:: M6

Supply Ability

Supply Ability: 10000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: To be packed in strong wooden cases or cartons, suitable for long distance ocean, parcel post or air freight transportation as well as changing climate and with good resistance to moisture and shocks.

Port: Shanghai Port

Lead Time:: Shipped in 45 days after payment

Product Description

Shoto 6 - SPB - 75 VRLA Maintenance - free Lead - acid AGM Spiral Battery for Telecom / Energy Storage / UPS

Normal Voltage		12V
Capacity		75Ah @ 10hr to 1.80V per cell @ 25˚C(77˚F)
Weight		25 kg (55.12 lbs)
Dimensions		Length: 263 mm Width: 178.5 mm Height: 240 mm Total height: 249 mm
Internal Resistance (full charged)		2.4 mΩ
Short - circuit Current		2695 A
Self Discharge @25˚C(77˚F)		Less than 8% after 90 days storage
Operating Temperature Range		Discharge: -45˚C ～ 75˚C(-49˚F ～ 167˚F) Charge: -20˚C ～ 50˚C(-4˚F ～ 122˚F) Storage: -20˚C ～ 40˚C(-4˚F ～ 104˚F)
Recommended Operating Temperature		15˚C ~ 35˚C
Recommended Charging Current		7.5A ~ 30A
Charging Voltage @25˚C(77˚F)		Float: 2.25 V/cell Cycle: 2.40 V/cell
Terminal		M6
Capacity Affected by Temperature		105 % @ 40˚C 95 % @ 0˚C 80 % @ -20˚
Design life @25°C		15 years

Main Applications

1. UPS

2. Communication station
3. Solar energy storage
4. Smart grid
5. Diferent standby power supply

Benefits

1. Applicable in -45°C ~ 75°C

2. The cycle life of 100% DOD reaches more than 350 times
3. The designed float life is 15 years
4. The time of high rate discharge is two times more than ordinary battery

Technical Features

1. With ultra-thin high purity lead frame design, a higher charge efciency with trickle current is achieved

2. With unique spiral wound design, the dehydration and bulging deformation of the battery are avoided in high-temperature
3. Excellent fast charging performance, more than 95% of electricity is gained within 40 minutes
4. Good battery consistency, available more strings in parallel

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
