AGM Sealed Lead Acid Battery 12V 120Ah 10hr Rate Valve Regulated

Contact Now

AGM Sealed Lead Acid Battery 12V 120Ah 10hr Rate Valve Regulated

Payment Terms :	L/C, T/T, Western Union

Place of Origin:	CHINA	Brand Name:	shoto
Certification:	CE / UL / ISO9001 / ISO18001 / ISO14001	Model Number:	6-GFM-120Ah

Detail Information
Weight:	30KG	Voltage:	12V
Size:	424174218/225mm	Capacity:	120Ah 10hr Rate
Nominal Capac:	120AH	Sealed Type:	Sealed
Usage:	Telecom, Energy Storage And UPS	Color:	Grey
Type:	Lead Acid Battery	Material:	High Pure Lead
Highlight:	10hr Rate Sealed Lead Acid Battery , 120Ah Sealed Lead Acid Battery , 120Ah battery valve regulated lead acid

Product Description

Valve-Regulated Lead-Acid Battery 6-GFM-120Ah

Overview

Quick Details

Brand Name:: Shoto

Model Number:: 6-GFM-120

Nominal Capacity:: 120AH

Place of Origin:: Jiangsu, China

Weight:: 35.5KG

Maintenance Type:: Free

Voltage:: 12V

Size:: 405*171*223/231mm

Sealed Type:: Sealed

Usage:: Telecom, Energy Storage and UPS

Application:: Telecom / Energy Storage / UPS

Color:: Grey

Certificate:: CE / UL / ISO9001 / ISO18001 / ISO14001

Battery type:: Sealed VRLA Lead Acid Battery

Type:: Lead Acid Battery

Product name:: 12V 120AH Lead Acid Battery

Capacity:: 120Ah 10hr Rate

Material:: High Pure Lead

Terminal:: M8

Supply Ability

Supply Ability: 10000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: To be packed in strong wooden cases or cartons, suitable for long distance ocean, parcel post or air freight transportation as well as changing climate and with good resistance to moisture and shocks.

Port: Shanghai Port

Lead Time:: Shipped in 45 days after payment

Product Description

Shoto 6 - GFM - 120 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS

Normal Voltage		12V
Capacity		120Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		35.5 kg (78.1 lbs)
Dimensions		Length: 405 mm Width: 171 mm Height: 223 mm Total height: 231 mm
Internal Resistance (full charged)		4.0 mΩ
Maximum Discharge Current		744A (5sec)
Self Discharge @25˚C(77˚F)		Less than 8% after 90 days storage
Operating Temperature Range		Discharge: -40˚C ～ 50˚C(-40˚F ～ 122˚F) Charge: -20˚C ～ 45˚C(-4˚F ～ 113˚F) Storage: -20˚C ～ 40˚C(-4˚F ～ 104˚F)
Recommended Operating Temperature		15˚C ～ 25˚C (59˚F ～ 77˚F)
Maximum Charging Current Limited		24A
Charging Voltage @25˚C(77˚F)		Float: 2.25 V/cell Cycle: 2.35 V/cell
Terminal		M8
Capacity Affected by Temperature		105 % @ 40˚C 85 % @ 0˚C 60 % @ -20˚
Design life @25°C		10 years

Main Applications

1. Backup power for telecom and signal system
2. Military field, railway system, power system
3. UPS & emergency lighting system
4. Fire alarm and security system

Benefits

1. 10 years design life
2. Safely and reliably sealed
3. High energy density, low internal resistance and low discharge rate
4. Excellent charging acceptability and high sealed reaction effciency

Technical Features

1. Adopt high strength ABS plastic, compact structure for battery container and valve, good impact resistance,and shock resistant performance.

2. Adopt multi-element alloy grids, low internal resistance, good corrosion resistance ability and charging acceptability.
3. New production process for plate, improve the utilization of active materiality.

4. High-purity electrolyte and special additives (ZL02112896.0), low self-discharge.

5. Multi-Iayer seal technology and special seal glue, no leakage and no acid mist escape, safe and reliable.

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
